| Tile Size |
469mm x 285mm |
| Minimum Roof Pitch |
22.5 degrees / For 12.5 degrees contact LBS |
| Minimum Headlap |
65mm |
| Maximum headlap |
100mm |
| Batten Spacing at Max Gauge |
405mm |
| Batten Spacing at Min Gauge |
365mm |
| Covering Capacity per sqm |
10 tiles per sqm at max gauge |
| Hanging Length |
445mm |
| Nominal Cover Width |
245mm |
| Weight per Tile |
3.7kg |
| Weight of Tiling per sqm (approx) |
37kg |
| Leading Edge Depth |
8mm |
| Battens Required per sqm approx. |
Min 2.47, Max 2.71 (linear metre) |
| Batten Size – up to 450mm rafter centres |
50x25mm |
| Batten Size – up to 600mm rafter centres |
50x37mm nb. special fixing req |
| Batten Size RoI |
45x35mm |
| Tile Nails |
Soltera Fixing System |
| Tile and Eave Clips |
Soltera Fixing System |
| Accessories Available |
Dry Verge, ridge and ventilation |
